XTRPRO124D Subwoofer 12" DVC 4-Ohm 1500 Watts RMS | 6000 Watts MAX
XTRPRO124D Subwoofer 12" DVC 4-Ohm 1500 Watts RMS | 6000 Watts MAX
Couldn't load pickup availability
The XTRPRO124D is a powerful 12" dual voice coil subwoofer with a peak power handling of 6000 Watts and RMS power handling of 1500 Watts. Featuring aluminum wound voice coils on a Kapton former and dual flat conex spiders with loop stitched tinsel leads, this subwoofer offers superior sound quality and durability. With a frequency response of 32 Hz - 1 kHz and a sensitivity of 89.3 dB, it provides a dynamic and immersive listening experience. Built with UV coated reinforced paper cone, Santoprene surround, and a proprietary cast aluminum frame, the XTRPRO124D is designed for long-lasting performance and can handle high power outputs with ease. Perfect for car audio enthusiasts and professionals seeking top-notch sound quality.
- Subwoofer Size:12 (Inches)
- Voice Coil Configuration:Dual 4-ohm
- Power Handling (Peak):6000 Watts
- Power Handling (RMS):1500 Watts
- Sensitivity:89.3 dB
- Frequency Response:32 Hz - 1 kHz
- Voice Coil Diameter:3 (Inches)
- Voice Coil Material:Aluminum Wound Voice Coil on a Kapton Former
- Spider:Dual Flat Conex Spiders with Loop Stitched Tinsel Leads
- Dustcap Material:Polypropylene
- Cone Material:UV Coated Reinforced Paper
- Surround Material:Santoprene
- Basket Material:Proprietary Cast Aluminum Frame
- Magnet Information:176 Oz Ferrite
- Speaker Displacement:0.1674 (cu. ft.)
- Mounting Depth:196mm / 7.70 (Inches)
- Cutout Diameter:284mm / 11.18 (Inches)
- Overall Diameter:322mm / 12.68 (Inches)
